Technical data
| Dimensions | 10cm x 25.5cm x 5.9cm (width x length x depth) |
| Weight | 715g |
| Spectral range | 390nm - 950nm 18 wavelength, peaks at 410/435/460/485/510/535/560/ 585/610/645/680/705/730/760/810/860/900/940nm 180° and 90° Setup for direct and indirect measurement |
| Parameters | more than 140 parameters (flexible setup) User defined parameter function |
| Electrodes | USB-type-C connector for pH/EC/TDS/ORP/Temp-Probes |
| Connectivity (technical) |
Bluetooth 4.2 WiFi USB (type C) 4G* (via USB-modem) |
|
Connectivity (software) |
LabCOM Software (Windows / Mac) LabCOM App (Android / iOS) LabCOM Cloud (web-browser) |
| Display | 5.5" Color-HD touch display |
| Camera | In-build barcode / QR-code scanner |
| Calibration | Auto-calibration function with certificate (software) |
| One-Time-Zero | Inteligent OTZ (One-Time-Zero) function with recognition of ZERO types |
| Internal memory | >5,000 |
| Clock/Date | RTC (Real-Time-Clock) with calendar function |
| Auto-Off | Factory default setting = 10 minutes. Individual adjustment possible |
| Menu guidance | Intuitive, display-controlled 4-button menu guidance; test instructions during measurement process |
| Power supply | 8,400 mAh lithium-ion battery |
| Languages | >15 |
| Environment | 5°C - 45°C / 30 - 90% rel. humidity |
| Water-proof rating | The device is splash-water-proof (IP54) |
| Reagents | The calibration curves for the individual parameters / measurement procedures are adjusted to the reagents offered by Water-i.d. Using reagents from other manufacturers may lead to wrong readings / higher tolerances. PrimeLab reagents are entirely "Made in Germany" or "Made in UK"! |
